No Cables & Wires – How To Build A BTF PC

It’s time to say goodbye to wires stretched across the interior of your chassis. Get ready to give a not-so-fond farewell to the power cable dangling off the side of your graphics card. To all the USB header cables, wires for power and reset buttons, and beefy 24-pin motherboard power cables: it’s been real, but we’re tired of looking at you. The future of PC building is clean, tidy, and simple. The ASUS BTF ecosystem of PC DIY components makes it possible to build a PC that tucks unsightly cables out of sight, and these parts are available today.

What Is BTF PC?

BTF stands for Back-to-the-Future, and it’s built on paradigm shift for constructing PCs. With BTF motherboards, components attach to the front, while cables plug into the back. This arrangement allows you to route your cables completely out of sight, leaving you with a fantastically clean-looking build.

ASUS BTF Motherboard

Only one question remains: which BTF components are best for your next PC? Here, we’ll introduce you to ASUS’ full lineup of options and help you find the ones that best fit your needs and budget. And if you act fast, you can even win a package of products from the BTF ecosystem by participating in the ASUS “The Ultimate Simplicity” giveaway campaign, running from May 27th, 2024 to June 30th, 2024. Read on for more details.

BTF vs. Advanced BTF: What’s the difference?

The ecosystem of BTF components gives you plenty of options as you’re planning a hidden-connector build. With the combination of a BTF chassis and a BTF motherboard, you can tuck away nearly all the cables that connect directly to the motherboard, including the cables that supply power to your motherboard, connect 2.5-inch SATA drives, hook up your case fans, and connect your front-panel buttons and I/O.

ASUS White BTF PC

Yet that’s not quite all the cables in a modern PC build equipped with a powerful graphics card. GPUs often require more power than the PCIe x16 slot can supply, so they require you to connect a PCIe power cable. For users that would prefer to hide that wire as well, we offer the Advanced BTF approach. Advanced BTF motherboards include a graphics card high-power slot ready to supply all the power that a BTF graphics card needs. You’ll need a graphics card with a graphics card high-power (GC-HPWR) gold finger in order to build an Advanced BTF PC.

Motherboard & Chassis Options For BTF PC

BTF Motherboards

The BTF ecosystem of PC components ranges from affordable options well within the reach of most builders to cutting-edge components designed for PC enthusiasts ready to push all boundaries. ASUS’ most budget-friendly BTF motherboards are the TUF Gaming B760M-BTF WiFi and TUF Gaming B760M-BTF WiFi D4, available in select countries.

ASUS BTF Motherboard 2

These B-series motherboards deliver incredible value for any builder who desires the effortless performance of a 14th Gen Intel Core CPU, but doesn’t intend to take advantage of CPU overclocking. While they don’t go toe-to-toe with ASUS high-end Z790 options, these microATX motherboards might surprise you with their rich feature set. They offer a PCIe 5.0 x16 slot that’s ready for the best graphics cards of today and tomorrow. A trio of onboard PCIe 4.0 M.2 slots make it easy to build a spacious and speedy storage array, and you’ll get fast networking with WiFi 6 and a 2.5Gb Ethernet port.

Since the TUF Gaming B760M-BTF WiFi and TUF Gaming B760M-BTF WiFi D4 hide all their connectors on the underside of motherboard, they offer a strikingly clean aesthetic. Their clean lines, inky black color scheme, and understated style make them an easy fit with a wide range of components.

 TUF Gaming B760M-BTF WiFiTUF Gaming B760M-BTF WiFi D4
SizemicroATX
Memory4 x DIMM, Max. 192GB, DDR54 x DIMM, Max. 128GB, DDR4
PCIe

1 x PCIe 5.0 x16 slot

1 x PCIe 4.0 x16 slot (@x4)

1 x PCIe 4.0 x1 slot

Storage3 x M.2 2280 (PCIe 4.0 x4)
Networking2×2 WiFi 6
1 x 2.5Gb Ethernet
AudioRealtek 7.1 Surround Sound High Definition Audio CODEC
Rear I/O1 x USB 20Gbps port (1 x USB Type-C®)
2 x USB 10Gbps ports (1 x Type-A + 1 x USB Type-C®)
3 x USB 5Gbps ports (2 x Type-A + 1 x USB Type-C®)
4 x USB 2.0 ports (4 x Type-A)
Front I/O1 x USB 10Gbps connector (supports USB Type-C®)
1 x USB 5Gbps header supports 2 additional USB 5Gbps ports
2 x USB 2.0 headers support 4 additional USB 2.0 ports
Aura3 x Addressable Gen 2 headers
1 x AURA RGB header
Cooling1 x 4-pin CPU Fan header
1 x 4-pin CPU OPT Fan header
1 x 4-pin AIO Pump header
3 x 4-pin Chassis Fan headers
Power1 x 24-pin Main Power connector
1 x 8-pin +12V Power connector
1 x 4-pin +12V Power connector

A BTF motherboard does require a BTF chassis with cutouts in the motherboard tray that allow you to access the connectors. ASUS have several cases for you to consider, and they have partnered with many chassis manufacturers to give you even more options. The most affordable model is the ASUS A21 case.

ASUS TUF BTF Build 2

This wallet-friendly microATX chassis is ready for BTF motherboards right out of the box. With its support for 360mm radiators, graphics cards up to 380mm in length, and CPU air coolers up to 165mm in height, you’ll get broad compatibility with today’s PC hardware. Its mesh front panel provides excellent airflow, and you’ll have ample space for cable management with its 33mm-wide compartment behind the motherboard. The ASUS A21 is available in black or white, and it includes color-matching cables for a tidy look — not that many people are going to ever see your cables in a BTF build.

Advanced BTF Motherboard

TUF GAMING Z790 BTF WiFi

TUF Gaming also gives you the components you need to construct an Advanced BTF build that goes the extra step to hide the PCIe power cables for your graphics card. It starts with a motherboard equipped with the necessary graphics card high-power slot: the TUF Gaming Z790-BTF WiFi.

This fully loaded board leans into a classy white aesthetic that’s a natural fit with the visual themes of BTF.  With an enhanced power solution with 16+1+1 power stages, a six-layer PCB, ProCool sockets, alloy chokes, and durable capacitors for stable power delivery, it’s more than ready for your 14th Gen Intel Core CPU. And that’s on top of WiFi 7 support, a 2.5Gb Ethernet port, an onboard USB 20Gbps Type-C port, and a total of four PCIe M.2 slots.

ModelTUF GAMING Z790-BTF WiFi
SizeATX
Memory4 x DIMM, Max. 192GB, DDR5
PCIe1 x PCIe 5.0 x16 slot
1 x PCIe 4.0 x16 slot (@x4)
1 x PCIe 4.0 x4 slot
Storage2 x M.2 22110 (PCIe 4.0 x4)
1 x M.2 2280 (PCIe 4.0 x4)
1 x M.2 2280 (PCIe 4.0 x4 & SATA)
NetworkingIntel® Wi-Fi 7
1 x Intel® 2.5Gb Ethernet
AudioRealtek ALC1220P 7.1 Surround Sound High Definition Audio CODEC
Rear I/O1 x USB 20Gbps port (1 x USB Type-C®)
3 x USB 10Gbps ports (2 x Type-A + 1 x USB Type-C®)
4 x USB 5Gbps ports (4 x Type-A)
Front I/O1 x USB 10Gbps connector (supports 1 x USB Type-C®)
1 x USB 5Gbps header supports 2 additional USB 5Gbps ports
2 x USB 2.0 headers support 4 additional USB 2.0 ports
Aura3 x Addressable Gen 2 headers
1 x AURA RGB header
Cooling1 x 4-pin CPU Fan header
1 x 4-pin CPU OPT Fan header
1 x 4-pin AIO Pump header
4 x 4-pin Chassis Fan headers
Power

1 x Graphics card high-power slot (delivers up to 600 watts)

1 x 24-pin Main Power connector

2 x 8-pin +12V Power connectors

1 x 12V-2X6 Auxiliary Power connector

3 x 8-pin PCIe Power connectors

GPU For Your BTF Build

TUF Gaming GeForce RTX™ 4070 Ti SUPER BTF White Edition

Your Advanced BTF build needs a GPU that’s ready to receive its power through the graphics card high-power slot. The TUF Gaming GeForce RTX 4070 Ti SUPER BTF White Edition is your ticket to the hidden-GPU-power-cable party with its graphics card high-power (GC-HPWR) gold finger. What’s more, it features a snowy white style that perfectly complements the TUF Gaming Z790-BTF WiFi.

Otherwise, it’s the TUF Gaming GeForce RTX 4070 Ti SUPER that you know and love. It delivers a high-end 1440p gaming experience, and its deep 16GB pool of VRAM makes it well-equipped to handle the VRAM-hungry games that we’re starting to see in the gaming market.  A generously oversized heatsink, a trio of Axial-tech fans, and a vented backplate work together to keep temperatures and fan noise low.

ModelTUF Gaming GeForce RTX™ 4070 Ti SUPER BTF White Edition
Graphics EngineNVIDIA® GeForce RTX™ 4070 Ti SUPER
CUDA Cores8448
OpenGL®OpenGL® 4.6
Engine Clock

OC mode : 2670 MHz

Default mode : 2640 MHz (boost)

Memory Interface256-bit
Video Memory16GB GDDR6X
Memory Speed21 Gbps
Power connectorGraphics card high-power (GC-HPWR) gold finger
I/O2 x Native HDMI® 2.1a
3 x Native DisplayPort™ 1.4a
Software

ASUS GPU Tweak III

GeForce Game Ready Driver

Studio Driver

Slot3.25-slot
Card Size305 x 138 x 65 mm

BTF Case For Your BTF PC

TUF Gaming GT302 ARGB

The eye-catching white surfaces of the TUF Gaming Z790-BTF WiFi and TUF Gaming GeFore RTX 4070 Ti SUPER BTF White Edition just might have you thinking about a color-matching PC case. For you, ASUS offers the TUF Gaming GT302 ARGB chassis.

Prepped and ready for great out-of-the-box cooling, equipped for wide compatibility with high-performance parts, and thoughtfully constructed inside and out for an easy PC DIY experience, the GT302 ARGB resets expectations for a mainstream case. On top of all that, it includes the motherboard tray cutouts you need to access the connectors on a BTF motherboard.

Product nameTUF Gaming GT302 ARGB
Motherboard CompatibilityE-ATX (up to 12″ x 10.9″), ATX, microATX, Mini-ITX
Dimension (W*H*D)235 x 520 485 mm
MaterialsSteel, Tempered Glass, ABS Plastic
I/O Ports

1 x USB 10Gbps USB Type-C®)

2 x USB 5Gbps (2 x Type-A)
1 x audio combo jack

3.5″/2.5″ Drive Bays2
2.5″ Drive Bays2
Expansion Slots8
Vertical Expansion Slots3
Maximum GPU Length407mm
Maximum CPU Cooler Height165mm
Maximum PSU Length220mm
Radiator CompatibilityFront: 140/280 mm
Top: 120/140/240/280/360 mm
Rear: 120/140 mm
Cooling SupportFront: 3 x 140 mm
Top: 3 x 140 mm / 3 x 120 mm
Rear: 1 x 140 mm / 1 x 120 mm
Pre-installed FansFront: 3 x 140 mm ARGB PWM Fan
Rear: 1 x 140 mm ARGB PWM Fan
Removable Dust FiltersFront/Top/Bottom
Cable Routing37mm

ROG Advanced BTF Build

ASUS’ most powerful and cutting-edge BTF components come from none other than their ROG lineup. With these parts serving as the foundation for your build, you’ll have more performance, more versatility, and more bold style — all in a super-clean Advanced BTF build.

ROG Motherboard For Your BTF PC

ROG MAXIMUS Z790 HERO BTF

The first BTF motherboard from ROG is none other than the ROG Maximus Z790 Hero BTF. This cutting-edge board is the perfect partner for a high-end 14th Gen Intel Core CPU thanks to its beefy VRM featuring 20+1+2 power stages. Thick VRM heatsinks keep this vital circuitry cool under pressure.  Across its impressive spec sheet, you’ll find an impeccable set of features: DDR5 support, a PCIe 5.0 x16 slot, a whopping 5 onboard M.2 slots, one wired for PCIe 5.0, dual onboard Thunderbolt 4 ports, WiFi 7, and more.

ModelROG MAXIMUS Z790 HERO BTF
SizeATX
Memory4 x DIMM, Max. 192GB, DDR5
PCIe1 x PCIe 5.0 x16 (@x16 or @x8)
1 x PCIe 4.0 x4
Storage

1 x M.2 22110 (PCIe 5.0 x4)

4 x M.2 2280 (PCIe 4.0 x4)

NetworkingIntel® Wi-Fi 7
1 x Intel® 2.5Gb Ethernet
AudioROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4082
Rear I/O

2 x Thunderbolt™ 4 ports (2 x USB Type-C®)

6 x USB 10Gbps ports (5 x Type-A + 1 x USB Type-C®)

4 x USB 5Gbps ports (4 x Type-A)

Front I/O

1 x USB 20Gbps connector (supports USB Type-C®)

2 x USB 5Gbps headers (support 4 USB 5Gbps ports)

2 x USB 2.0 headers (support 4 USB 2.0 ports)

Aura

3 x Addressable Gen 2 headers

1 x AURA RGB header

Cooling

1 x 4-pin CPU Fan header

1 x 4-pin CPU OPT Fan header

1 x 4-pin AIO Pump header

4 x 4-pin Chassis Fan headers

1 x W_PUMP+ header

Power

1 x Graphics card high-power slot (delivers up to 600 watts)

1 x 24-pin main power connector

2 x 8-pin +12V power connectors

1 x 12V-2X6 Auxiliary power connector

Partner It With An ROG GPU

ROG Strix GeForce RTX™ 4090 BTF Edition

The high-end ROG Maximus Z790 Hero BTF motherboard deserves an equally mighty partner in crime. So for the first graphics card to represent ROG on the BTF front, ASUS ROG went straight to the top. The ROG Strix GeForce RTX 4090 BTF Edition graphics card takes their highest-performance ROG Strix GPU and gives it even cleaner aesthetics by swapping out the traditional 16-in external power connectors for a graphics card high-power (GC-HPWR) gold finger.

Without the power cable hanging off the side — and without any follow-up worries about whether you’ve firmly and completely inserted that connector — you’ll be better able to appreciate everything this potent graphics card has to offer. Built with one of the finest GPU cooling solutions we’ve ever designed, this large-and-in-charge card stays cool and quiet with its massive heatsink, scaled-up Axial-tech fans, and patented vapor chamber. The diecast shroud, frame, and backplate add rigidity and are vented to maximize airflow and heat dissipation.

ModelROG Strix GeForce RTX™ 4090 BTF Edition
Graphics EngineNVIDIA® GeForce RTX™ 4090
CUDA Cores16384
OpenGL®OpenGL® 4.6
Engine Clock

OC mode: 2640 MHz

Default mode: 2610 MHz (Boost Clock)

Memory Interface384-bit
Video Memory24GB GDDR6X
Memory Speed21 Gbps
Power connectorGraphics card high-power (GC-HPWR) gold finger
I/O2 x Native HDMI® 2.1a
3 x Native DisplayPort™ 1.4a
Software

ASUS GPU Tweak III

GeForce Game Ready Driver

Studio Driver

Slot3.5-slot
Card Size357.6 x 149.3 x 70.1 mm

The ROG Case For Your ROG BTF PC

ROG Hyperion GR701 BTF Edition

Let’s wrap up your ROG Advanced BTF build in a chassis that’s worthy of the moment. A special edition of ASUS ROG’s award-winning chassis, the ROG Hyperion GR701 BTF Edition takes the original’s premium feature set and adds motherboard tray cutouts perfectly positioned for you to access the connectors of your BTF motherboard.

Like the original, it boasts outstanding cooling performance with its dual 420mm radiator support, four 140mm fans, and a built-in fan hub. It offers plenty of elbow room for even the beefiest of graphics cards, and it aids your build process with a 34mm-deep cable management chamber with a 46mm-wide routing channel.

ModelROG Hyperion GR701 BTF Edition
Motherboard CompatibilityEATX (up to 12” x 10.9”), ATX, microATX, Mini-ITX
Dimensions (L x W x H)268 x 639 x 659 mm
MaterialsAluminum, Steel, Tempered Glass, ABS Plastic
I/O Ports2 x USB 20Gbps port (2 x USB Type-C®)
4 x USB 5Gbps (4 x Type-A)
1 x Headphone + 1 x Microphone
Front control button1 x LED lighting control button
1 x Reset
ARGB Fan HubYes, Support PWM Fan x 6, ARGB LED component x 8
3.5”/2.5” Drive Bays2
2.5” Drive Bays4
Expansion Slots9 x Horizontal PCIe
3 x Vertical PCIe
Maximum GPU Length460 mm
Maximum CPU Cooler Height190 mm
Maximum PSU Length240 mm
Radiator CompatibilityFront: 120, 140, 240, 280, 360, 420 mm
Top: 120, 140, 240, 280, 360, 420 mm
Rear: 120, 140 mm
Side: 120, 240, 360 mm
Cooling SupportFront: 3 x 140 / 3 x 120 mm
Top: 3 x 140 mm / 3 x 120 mm
Rear: 1 x 140 / 1 x 120 mm
Side: 3 x 120 mm
Pre-installed FansFront: 3 x 140 mm PWM
Rear: 1 x 140 mm PWM
Additional AccessoryROG screw driver
Removable Dust FiltersFront two sides: Slide-out
Top: fix with screw
Bottom: Slide-out
Cable RoutingMax. 34mm

Picking A Power Supply

Let’s talk about power supplies. Even though BTF motherboards change many things about the process of building a PC, they’re compatible with standard power supplies, so you do have a full market of options. That said, we think you’ll have a more seamless building experience when you use an ASUS power supply for your BTF build. ROG and TUF Gaming power supplies are equipped with flexible embossed power cables that make cable routing easier. Furthermore, all ASUS BTF components have undergone stricter validation tests with ASUS power supplies to ensure the best compatibility, stability, and performance.

ASUS offers a wide range of power supply options for you to consider from ROG, TUF Gaming, and Prime product families so that you can get a high-quality option that fits your needs and budget. To learn the differences between each series and get an easy breakdown of how to pick a PSU, click here.

ROG Thor 1000W Platinum II

If you’d prefer a quick recommendation instead, get one of the high-wattage ROG Thor PSUs for an ROG BTF build, like the ROG Thor 1000W Platinum II. For your TUF Gaming BTF build featuring the TUF Gaming GeForce RTX 4070 Ti Super BTF White Edition, the TUF Gaming Gold series offers complementary style and battle-proven durability at a great price. The TUF Gaming 750W Gold might be the perfect choice.

More Chassis Options From The BTF Alliance

As proud as ASUS are in the ROG Hyperion BTF and TUF Gaming GT302, they know that builders like to have a full menu of options as they’re picking out a chassis for their next PC. That’s why they’ve partnered with many of the biggest names in the PC case industry to create the BTF Alliance. Through this partnership, you’ll have your choice from a wide range of PC cases that are fully compatible with ASUS BTF motherboards. Options from Aerocool, be quiet!, Cooler Master, Corsair, DIY APE, InWin, Lian Li, Phanteks, Silverstone, and Thermaltake are all in the works, and many are available right now.

Corsair 6500X

If you’d like a panoramic view of your gear and a dual-chamber layout, check out the Corsair 6500X.

MasterBox 600

Cooler Master has added the MasterBox 600 to its popular MasterBox lineup, and on top of BTF motherboard support it offers optimized airflow, versatile cooling options, and two color options.

nWin F5

The InWin F5 stands out from the pack with striking style and great out-of-the-box cooling, and the InWin D5 offers a fresh take on the classic black PC chassis.

You’ll have a chance to win one of these BTF chassis options from ASUS partners through the “The Ultimate Simplicity” giveaway campaign.

Build A New PC With This Exclusive Giveaway

The Ultimate Simplicity

The ASUS BTF ecosystem of motherboards, graphics cards, and PC cases ushers in a new era of PC building. The interior of your PC no longer needs to include a visible tangle of cables and wires stretching every which way. With BTF components, you can keep them tucked out of sight from the start of your building process.  And through ASUS’ partnership with a wide variety of PC chassis manufacturers, you have a wealth of options for picking parts for your custom BTF PC build.

The Ultimate Simplicity 2

To help you get started on your BTF setup, we’re running an exclusive giveaway from May 27th, 2024 to June 30th, 2024. The prize list is stacked from top to bottom: one lucky winner will take home the ROG Maximus Z790 Hero BTF and the ROG Strix GeForce RTX 4090 BTF Edition, and another will take home the TUF Gaming Z790-BTF WiFi and the TUF Gaming GeForce RTX 4070 Ti SUPER BTF White Edition. Other prize winners will score a BTF chassis from ROG, TUF Gaming, Corsair, Cooler Master, or InWin and a BTF motherboard that’s a perfect aesthetic fit. And we have a stack of ROG Falchion RX Low Profile gaming keyboards, ROG Gladius III Wireless AimPoint gaming mice, and ROG Cetra True Wireless SpeedNova gaming headphones that we’re ready to give out, as well.

This is a limited-time giveaway, so don’t wait to head over to the giveaway site for all the details on this exclusive opportunity.
